Theming support in an application can be pretty useful. From nice to have feature like letting user to chose from available color schemes to get personalized experience to more mission critical branding capabilities like building multi-tenant SaaS product where every client wants to use their own domain, logo and colors to offer branded services to their end customers.
Lately I have been working on Angular ngRx Material Starter project and surprisingly, one of the best features of new Angular Material component library proved to be its theming capabilities. It enables us to implement beautiful themes with only a little effort on our side!
Unfortunately, as of June 2017, the official theming documentation seems to be a bit lackluster and it takes a while to figure out how the whole thing actually works and how to get access to the needed colors defined as a part of the theme.
Anatomy of a theme
Defining a theme in Angular Material is extremely simple, all we need to do is to create a theme file, select three color palettes for the main theme colors — primary, accent and warn — and we are all set!
Feel free to explore all the palettes that are available out of the box.
The numbers behind the palette variable name select particular shades of chosen color for default, lighter and darker variants. If no numbers are provided Angular Material selects sensible defaults
$default: 500, $lighter: 100, $darker: 700.
Yeah cool, variable names and numbers, but what does it mean in practice?!
No worries I got your back 😉
Even though every palette contains accent shades (eg: A100), we don’t necessarily need to use them as the accent color of our theme, we may simply choose different palette instead.
In example above, theme variable
$my-theme-accentis set to
$mat-light-bluepalette instead of accent shades of
$mat-indigopalette which is used for
Check out all the out of the box available Material Colors.
In the code example above we created our theme using
mat-light-theme function. This means that all the other “neutral” colors of our theme will be various shades of black and white with mostly white (or very light grey) backgrounds and mostly dark elements like text, dividers, shadows …
Angular Material provides also
mat-dark-theme function which does exactly the opposite — dark backgrounds and light elements. We will get into more details of these two later…
Do you wan’t to stay up to date with releases of Angular Material? Follow Release Butler, a Twitter bot I created that tweets beautiful changelogs of popular frontend libraries!
Using our custom themes
Great, we defined our custom theme but that doesn’t do anything by itself. Next step is to include our custom theme in main style file of our application (usually
Using specific css class for single theme is not necessary per se but it will help us when adding additional themes
Adding multiple custom themes
To use multiple themes we simply need to import additional themes and create respective css classes for each theme.
Theme class and overlay handling
Depending on our particular use case we might need to implement some dynamic css class switching (with
[class]) to enable user to switch themes using application preferences during runtime or use parametrized build (eg: define variable in webpack) to build our application using desired theme by adding correct css class to the
<body> tag during build.
Angular Material contains components like dropdown or dialog which create overlay over the application's default layout, to theme these elements we have to set theme class also on the
Cool our application now supports use of potentially unlimited number of different themes🎨🌈. This is useful in itself but these themes will only style components provided by the Angular Material library itself. While there are quite some components available (and even more are waiting in the pipeline for the future releases) almost no application can do without implementing some custom components.
Follow me on Twitter to get notified about the newest blog posts and interesting frontend stuff
Theming our custom components
Let’s say we are going to implement our own custom “big input” component in shared module. Using
@angular/cli we will execute command which will look something like
ng generate component shared/big-input --module shared.module. This will generate component, template and style files. We will put our general layout and styling to the
big-input.component.scss but we will also create new file
big-input.component.scss-theme.scss where we will use style rules which have anything to do with color.
<component-name>.component.scss-theme.scssis not official naming convention, I found it very helpful because IDE will put original styles file and theme file next to each other based on default alphabetical ordering.
The custom component theme file then will look something like this…
In our mixin, we retrieved all the available theme variables to demonstrate what is possible but in real project we should only retrieve what is necessary…
These variables then contain many sub-values based on the variable type.
$warn variables contain reference to the whole palette as we defined in our custom theme definition in the beginning of article.
We can retrieve particular colors using
mat-color function. We can select default, lighter and darker shades (eg:
mat-color($primary, lighter)) as defined by our theme or even any available color of the palette when necessary (
It can be useful to retrieve appropriate contrast color when using main color as a background for some component which also contains text. In that case we can retrieve corresponding contrast color, eg:
mat-color($primary, lighter-contrast) for backgrounds which
Foreground and background color sub-values
$warn variables contain same sub-values because they are created in a same way using
$background are a bit different. We don’t define them by hand but Angular Material sets their colors based on the function we use to create our custom theme. There are two available functions —
mat-dark-theme and available sub-values are…
Using custom component themes
To use our custom component theme we have to include it in main styles.scss file.
It is a good practice to create separate
custom-components-thememixin where we can collect all of our custom components so that we don't have to repeat all of them for every custom theme class
🤫 Psst! Do you think that NgRx or Redux are overkill for your needs? Looking for something simpler? Check out @angular-extensions/model library!
Defining custom palette
Angular material provides quite some palettes out of the box and many times it will be enough but sometimes we will need to use colors defined in company’s design manual to achieve consistent branding of the product.
In that case we can simply create
custom-palettes.scss file and create our own palette variables (eg:
$my-company-blue) with all the sub-values which are contained in standard Angular Material palettes like 100, 200, contrast, …
Then we simply import this file in the custom theme definition file so that we can use the provided values.
